◆ Network scale Single frequency supports 64/128*/256* notes（*Optional）

◆ Frequency 560~680MHz / 1300~1530MHz，1MHz step adjustable；（70~6000MHz customizable）

◆ Anti-interference intelligent frequency selection*, broadband frequency hopping*（*Optional selection）

◆ Output power 40W：2x20W,1dBm step adjustable

◆ Bandwidth 1.25 / 2.5 / 5 / 10 / 20* / 30* / 40*MHz（*Optional selection）

◆ Receive sensitivity -103dBm@5MHz

◆ Peak rate 220+Mbps@40MHz

◆ Range 300+km（LOS）

◆ Interface 100M LANx2、UARTx3（TTL、RS232、RS422、RS485 customizable）

◆ Voice IP voice conference/PTT intercom (standard PTT microphone)

◆ Secure encryption DES/AES128/AES256

◆ Power consumption 20~200W

◆ Latency about 7ms

◆ Working temperature -20~+55℃（standard）；-40~+55℃（customized）

◆ Dimensions 380x218x63mm

◆ Bare weight about 4.20kg

Note For detailed parameters, please contact us to obtain the product specification manual
